K3-90A00-230V contactor

The K3-90A00-230V contactor by Benedikt & Jäger is a three-pole device designed for switching electrical circuits with a rated operational current of up to 90 A at 400 V in AC-3 category. Its 230 V AC/DC coil makes it suitable for various industrial ...

Order number: K3-90A00

Add to compare list Add to favourites

The K3-90A00-230V contactor by Benedikt & Jäger is a three-pole device designed for switching electrical circuits with a rated operational current of up to 90 A at 400 V in AC-3 category. Its 230 V AC/DC coil makes it suitable for various industrial and commercial applications.

Technical Specifications

Parameter	Value
Number of Poles	3
Rated Operational Current (Ie)	90 A at AC-3, 400 V
Rated Power	45 kW at AC-3, 400 V
Coil Voltage	230 V AC/DC
Coil Voltage Range	220–240 V AC, 50/60 Hz; 220 V DC
Operating Temperature	-40 °C to +90 °C
Connection	Screw terminals
Auxiliary Contacts	None (0 NO + 0 NC)
Mounting	DIN rail or screw mounting
Protection Rating	IP20

Advantages

Compact Design: Saves space with its small footprint.
High Durability: Operates reliably in a wide temperature range from -40 °C to +90 °C.
Versatile Use: AC/DC coil compatibility broadens application scope.

The K3-90A00-230V contactor is ideal for reliable control of electric motors and other loads in industrial systems, emphasizing performance and reliability.

Jmenovité napětí	230
Výkon kvar 400 V - 440 V	80
Výkon kvar 660 V - 690 V	120
Jmenovitý proud [A]	115
Width [mm]	90
Depth [mm]	120
Height [mm]	155
Hmotnost v [g]	2200
Mounting type	For DIN rail
Provozní teplota	-40... +60 °C

Návody

K3-90A00-to-K3-115A00-Datasheet.pdf

Stáhnout

Benedict kompenzační stykače katalog EN.pdf

Stáhnout

K390A00 K3 115 A00.jpg

Stáhnout
